RB401T-E
Rebar Tying Tool up to 20mm x 20mm with 1.0 mm wire
Stand Up Rebar Tying Tool up to 20mm X 20mm
Applications
- Road and Bridge
- Foundations
- Water retaining Structures
- Commercial Buildings
- Water Treatment Tanks
Features
- DOUBLE THE SPEED
The Dual Wire Feeding Mechanism increases productivity. - COST SAVINGS
The Wire Pull Back Mechanism dispenses the precise amount of wire needed to form a tie reducing wire usage. - THE TWINTIER
The TwinTier can tie 4000 ties per battery charge and up to 240 ties per coil of wire (on 13mm x 13mm rebar). - SHORTER TIE HEIGHT
The TwinTier's Wire Bending Mechanism (Pat. Pending) produces a shorter tie height. Less concrete is needed to fully cover a wire tie. - A LARGE JAW
A large jaw enables the TwinTier to tie up to a 20mm x 20mm rebar. - AN EASY PUSH GEAR
An easy push gear release effortlessly opens gears to quickly feed wire when loading the tool.
Specifications
DIMENSIONS | 1100mm(H) x 408mm(W) x 322mm(L) |
|---|---|
MINIMUM TIES PER COIL | 155 |
MAXIMUM TIES PER COIL | 260 |
APPLICABLE WIRE PRODUCT | TW1061T / 19Ga, TW1061T-PC / 19Ga, TW1061T-EG / 19Ga, TW1061T-S / 19Ga, |
APPLICABLE REBAR SIZE | 10 x 10 - 20 x 20, up to 13 x 13 x 13 x 13(Unit: mm) |
TIES PER CHARGE | 4000 |
TIE SPEED | 0.7 sec |
TIE WRAPS | 2 |
BATTERY CHARGE TIME | 65 minutes full charge (50 minutes 80%) |
Consumables / Accessories
Tool, Owners manual, Battery, Charger, Carry case
Manuals
Owner's Manual
Download
